ZyXEL SBG5500-A,Annex A

ZyXEL SBG5500-A,Annex A

Small Business Gateway

Zyxel SBG5500-A,Annex A version,EU, UK and USA,RoHs
PN: SBG5500-A-ZZ0101F
skladem
6 890 Kč
8 337 Kč vč. DPH | Běžná cena: 9 171 Kč

Vložit do košíku

Na Vaše přání Vám zakoupené produkty rádi a ochotně nainstalujeme, nakonfigurujeme a samozřejmě Vás zaškolíme v jejich užívání a ovládání. Máte-li zájem o naše servisní služby, kontaktujte naše zákaznické centrum.

Podrobné info

The ZyWALL SBG5500 / 3310 Series has been designed for small business and start-up company networks. It provides Internet connections of high reliability, performance and security for remote offices and telecommuters; it also meets performance and security need of your employees for the busines to maintain high efficiency and productivity.

Oblast použití

Příklad zapojení SBG5500-A,Annex A

Funkce

VPN applications

  • Organizations, branch offices, partners and home users can deploy Zyxel ZyWALL SBG5500/3310 Series for Site-to-Site IPSec VPN and L2TP over IPSec VPN clients.
  • VPN is a solution to establishing secured network connections and reducing long-distance telephone charges.
  • Users can establish wireless VPN connections to protect sensitive information being transmitted.
  • Remote users can securely access company resources with their computers or smartphones via Zyxel’s SBG VPN.
  • The ZyWALL SBG5500/3310 Series can establish a L2TP VPN connections to service providers for secured Internet access.

Technické parametry

Hardware Specifications
10/100/1000 Mbps RJ-45 ports   4 x LAN, 1 x WAN/LAN, 1 x WAN, 1 x SFP
DSL ports   1 x VDSL2/ADSL2+ (RJ-11/RJ-45)*1
USB ports   1* USB3.0
Console port   Yes (DB9)
Rack-mountable*2   Yes
Fanless   Yes
System Capacity & Performance*3
SPI firewall throughput (Mbps)*4   1,300
VPN throughput (Mbps)*5   150
Max. TCP concurrent sessions*6   100,000
Max. concurrent IPsec VPN tunnels *7   50
Customizable zones   Yes
IPv6 support   Yes
VLANs   16
Key Software Features
Multi-WAN Load Balance/Failover   Yes
Virtual private network (VPN)   Yes (IPSec, L2TP over IPSec, PPTP, L2TP)
VPN Client   IPSec/L2TP
Firewall   Yes
VLAN/Interface Group   Yes2
Bandwidth management   Yes
Logging and monitoring   Yes
Cloud Helper   Yes
Remote Management   Yes
Power Requirements
Power input   110-240 V AC, 50/60 Hz, 2 A max.
Max. power consumption (watt)   10.95
Heat dissipation (BTU/hr)   37.36
Physical Specifications
Item dimensions (WxDxH) (mm/in.)   272 x 180.74 x 39.5/ 10.7 x 7.11 x 1.55
Item weight (kg/lb.)   1.5/3.3
Packing dimensions (WxDxH) (mm/in.)   468 x 250 x 72/ 18.42 x 9.84 x 2.83
Packing weight (kg/lb.)   2.4/5.29
Included accessories   Power adapter
Environmental Specifications
Operating Temperature   0°C to 50°C (32°F to 122°F)
Operating Humidity   10% to 90% (non-condensing)
Storage Temperature   -40°C to 70°C (-40°F to 158°F)
Storage Humidity   10% to 90% (non-condensing)
MTBF (hr)   44,000
Certifications
EMC   FCC Part 15B (Class B) FCC Part 68 CE EMC (Class B) BSMI
Safety   CE LVD, BSMI
Models
Hardware Specifications
10/100/1000 Mbps RJ-45 ports
DSL ports
USB ports
Console port
Rack-mountable*2
Fanless
System Capacity & Performance*3
SPI firewall throughput (Mbps)*4
VPN throughput (Mbps)*5
Max. TCP concurrent sessions*6
Max. concurrent IPsec VPN tunnels *7
Customizable zones
IPv6 support
VLANs
Key Software Features
Multi-WAN Load Balance/Failover
Virtual private network (VPN)
VPN Client
Firewall
VLAN/Interface Group
Bandwidth management
Logging and monitoring
Cloud Helper
Remote Management
Power Requirements
Power input
Max. power consumption (watt)
Heat dissipation (BTU/hr)
Physical Specifications
Item dimensions (WxDxH) (mm/in.)
Item weight (kg/lb.)
Packing dimensions (WxDxH) (mm/in.)
Packing weight (kg/lb.)
Included accessories
Environmental Specifications
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
MTBF (hr)
Certifications
EMC
Safety

Note:

  1. *: This matrix with firmware OPAL BE 1.10 or later.
  2. *: RJ-11 is for Annex A, while RJ-45 is for Annex B
  3. *: Rack-mount kit is optional
  4. *: Actual performance may vary depending on network conditions and activated applications.
  5. *: Maximum throughput based on RFC 2544 (1,518-byte UDP packets).
  6. *: VPN throughput measurement based on RFC 2544 (1,424-byte UDP packets).
  7. *: Maximum sessions measured using the industry-standard IXIA IxLoad testing tool.
  8. *: Including Gateway-to-Gateway and Client-to-Gateway.
